Axial angular contact ball bearing (three-row) - DKLFA
| Description | Main dimensions | Functions | ||
|---|---|---|---|---|
| d | B | di | ||
| mm | mm | mm | ||
| SKU | Description | Main dimensions | Functions | ||
|---|---|---|---|---|---|
| d | B | di | |||
| mm | mm | mm | |||
| 10315514 | DKLFA1575-2RS | 15.00 | 32.00 | 75.00 | |
| 10315515 | DKLFA2080-2RS | 20.00 | 35.00 | 80.00 | |
| 10315516 | DKLFA2590-2RS | 25.00 | 38.00 | 90.00 | |
| 10315517 | DKLFA30100-2RS | 30.00 | 38.00 | 100.00 | |
| 10315518 | DKLFA30110-2RS | 30.00 | 56.00 | 110.00 | |
| 10315519 | DKLFA40115-2RS | 40.00 | 42.00 | 115.00 | |
| 10315520 | DKLFA40140-2RS | 40.00 | 60.00 | 140.00 | |
Online Datasheet (Variants, 3D-View)
PDF-Datasheet
Link to shop
Product request
