Four-point contact slewing bearing, light seires 20, non-toothed, bearing clearance selectable, sealed, Grease nipple on the circumference of the outer ring
Four-point contact slewing bearing VLU 20
Four-point contact slewing bearing VLU 20
SKU
Description
Main dimensions
Functions
d
D[[sub]]i[[/sub]]
d[[sub]]a[[/sub]]
mm
mm
mm
10096288
VLU200414 518.00 -0.50 +0.50 415.50
412.50 -0.50
10096289
VLU200544 648.00 -0.50 +0.50 545.50
542.50 -0.50
10096290
VLU200644 748.00 -0.60 +0.60 645.50
642.50 -0.60
10096291
VLU200744 848.00 -0.60 +0.60 745.50
742.50 -0.60
10096292
VLU200844 948.00 -0.60 +0.60 845.50
842.50 -0.60
10096293
VLU200944 1,048.00 -0.70 +0.70 945.50
942.50 -0.70
10096294
VLU201094 1,198.00 -0.70 +0.70 1,095.50
1,092.50 -0.70
