Thin section angular contact ball bearing - CSED
Thin section bearing - CSED
Thin section bearing - CSED
SKU
Description
Main dimensions
Functions
d
D
B
mm
mm
mm
10147420
CSED040 101.60
127.00
12.70
10157443
CSED042 107.95
133.35
12.70
10147421
CSED045 114.30
139.70
12.70
10157445
CSED047 120.65
146.05
12.70
10147422
CSED050 127.00
152.40
12.70
10147423
CSED055 139.70
165.10
12.70
10147424
CSED060 152.40
177.80
12.70
10147425
CSED065 165.10
190.50
12.70
10147426
CSED070 177.80
203.20
12.70
10157447
CSED075 190.50
215.90
12.70
10147427
CSED080 203.20
228.60
12.70
10147428
CSED090 228.60
254.00
12.70
10147429
CSED100 254.00
279.40
12.70
10147430
CSED110 279.40
304.80
12.70
10147431
CSED120 304.80
330.20
12.70
10147432
CSED140 355.60
381.00
12.70
10147331
CSED160 406.40
431.80
12.70
10147433
CSED180 457.20
482.60
12.70
10157449
CSED200 508.00
533.40
12.70
10157451
CSED210 533.40
558.80
12.70
10157453
CSED250 635.00
660.40
12.70
10157455
CSED300 762.00
787.40
12.70
